Engine mounts BMW E36 /E46 - Toyota 1JZ /2JZ
Engine mounts BMW E36 /E46 - Toyota 1JZ /2JZ - Image 2
Engine mounts BMW E36 /E46 - Toyota 1JZ /2JZ - Image 3
Weight 4 kg
BMW

Engine mounts BMW E36 /E46 – Toyota 1JZ /2JZ

269,50 €

This item is low in stock.

Item(s) left: 0

Pas garantie

Op maat voor jouw auto

Niet tevreden, geld terug

14 dagen bedenktijd

Description

DESCRIPTION

These mounts have a bolt pitch that should fit 1JZ /2JZ GE and GTE. The brackets are made to fit with a rear-mounted oil pan.

The corners of the trough against the front beam may need to be massaged in a little with a hammer to create some space against the beam that is very close otherwise.

SPECIFICATIONS
  • A stable rubber bushing keeps the engine in place.
  • They are made of 5mm high-strength steel sheet and are Zinc iron chromated and black-passivated. A good quality of galvanizing that the automotive industry often requires.
  • A set of brackets consists of: 4 brackets incl bushings, 2 bolts, nuts and washers. 2 M10x20 screws, 2 M10 nuts to attach to the front beam with. The brackets are then screwed together with the bolt from the joint bearing to the link arm. These brackets also include bolts for mounting the brackets to the block as it is of the unusual dimension M10x1,25×20.
